Home off grid hybrid dc ac inverter integrated charge controller
all in one solar power system home solar generator
Product Description:
The Low Frequency Solar Inverter is a Hybrid Off-Grid Inverter
designed to provide reliable and efficient power conversion for
both AC and DC systems. It is capable of withstanding an overload
of 110-125% for 60 seconds and 125-150% for 10 milliseconds. It
operates in an environment of 0-90% humidity and noise levels of
≤60dB. The output frequency is adjustable between 50/60Hz and the
input voltage can be set between 85-135VAC/165-265VAC. Low
Frequency Solar Inverter is the perfect solution for providing
reliable and efficient solar energy for both commercial and
residential applications.
Features:
- Product Name: Low Frequency Solar Inverter
- Durability: High Durability
- Altitude: 2000m
- Operating/storage environment: 0-90%
- Input Voltage: 85-135VAC/165-265VAC
- Storage ambient temperature: -15 ℃~+50 ℃
- Lifepo4 Home Storage System
- Hybrid Off-Grid Inverter
- Solar Inverter storage
Technical Parameters:
| Parameter | Value |
|---|
| Durability | High Durability |
| Output Frequency | 50/60Hz |
| Operating/storage environment | 0-90% |
| Colloidal cell capacity | 680WH-9600WH |
| Input Voltage | 85-135VAC/165-265VAC |
| Overload | 110-125% 60S 125-150%10MS |
| Altitude | 2000m |
| Storage ambient temperature | -15 ℃~+50 ℃ |
| Grid voltage range | 85-135VAC/165-265VAC |
| Output Current | 0-30A |
Applications:
KOMCO KO-ESP Low Frequency Solar Inverter is the perfect choice for
your solar power inverter needs. It is proven to be highly durable
with its 260*480*470 dimension, and is designed to ensure optimal
performance in a wide range of operating and storage environments,
from 0-90%. It can withstand temperatures ranging from -15 ℃~+50 ℃
and is designed to handle an overload of 110-125% for 60S and
125-150% for 10MS. Its high durability ensures that it performs
efficiently and reliably for years. KOMCO KO-ESP Low Frequency
Solar Inverter is the perfect choice for energy storage and
providing long-term, reliable power.
Customization:
KOMCO Low Frequency Solar Inverter
Brand Name: KOMCO
Model Number: KO-ESP
Place of Origin: China
Size: 260*480*470
Output Frequency: 50/60Hz
Cooling System: High Efficiency Cooling System
Durability: High Durability
Storage ambient temperature: -15 ℃~+50 ℃
KOMCO Low Frequency Solar Inverter is perfect for solar power
system. It has high efficiency cooling system and high durability,
which can store ambient temperature from -15 ℃ to +50 ℃. The size
is 260*480*470 and the output frequency is 50/60Hz.
Specification
Technical parameters |
Model(ESP) | 1000 | 2000 | 3000 | 5000 | 6000 | 7000 |
Rated power(W) | 1500W | 2000W | 3000W | 5000W | 6000W | 7000W |
peak value(W)ms | 2kw | 4kw | 6kw | 10kw | 12kw | 14kw |
Install | Floor mounted |
Internal battery | | Colloidal battery/lithium iron phosphate |
Colloidal cell capacity | 680WH-9600WH | optional |
Iron lithium battery capacity | 1000WH-20480WH |
Mains input | Grid voltage range | 85-135VAC/165-265VAC |
power frequency | 45-65Hz |
Mains bypass | YES |
Mains complementation | YES |
Mains charging | 0-30A |
Input circuit breaker | YES |
Photovoltaic input | open-circuit voltage | 50VDC/100VDC/150VDC |
Controller current | 30A/60A/100A |
charge mode | MPPT maximum power tracking |
Surge protection against lightning | YES |
main incoming circuit-breaker | YES |
Ac output | output waveform | pure sine wave |
output voltage | 110VAC/ 220VAC±5% |
frequency | 50Hz/60Hz±0.3Hz |
power factor | 1 |
transfer efficiency | 88%±3% |
transfer time | <8ms |
Output circuit breaker | YES |
| 5VUSB | 3*QC3.0 |
| 12VDC | 5521*2 5A |
Protect function | Over voltage protection, under voltage protection, overload
protection, short circuit protection, over temperature protection,
surge protection, etc |
Overload | 110-125% 60S 125-150%10MS |
Storage ambient temperature | -15 ℃~+50 ℃ |
Operating/storage environment | 0-90% |
Altitude | 2000m |
Communication interface | RS485(WIFI/GPRS) |
Noise | ≤60dB |
Heat dissipation | forced cooling |
SIZE | 260*480*470 | 540*365*570 | 609*550*1000 |
Applications:
Support and Services:
Low Frequency Solar Inverter Technical Support and Services
Our Low Frequency Solar Inverter comes with technical support and
services to ensure that you have a smooth and successful
installation and use of the product.
Installation Support
Our team of experienced engineers and technicians are always
available to provide guidance and advice on the installation of
your Low Frequency Solar Inverter. We will provide detailed
instructions and diagrams to make sure that the installation
process is completed safely and correctly.
Maintenance and Troubleshooting
We offer a comprehensive maintenance and troubleshooting service
for our Low Frequency Solar Inverter. We will help you identify
problems and provide step-by-step solutions to resolve any issues
you may encounter. We also provide regular check-ups and
maintenance to ensure that your inverter is running optimally.
Customer Service
Our customer service team is available to answer any questions you
may have regarding the installation, maintenance, or
troubleshooting of your Low Frequency Solar Inverter. We strive to
provide the best customer service possible, and we are always happy
to help in any way we can.
Packing and Shipping:
Packaging and Shipping
The Low Frequency Solar Inverter is carefully packaged and shipped
in a box, with the following precautions to ensure that it arrives
in good condition:
- The inverter is placed in a foam-lined inner box to protect it from
shock
- The box is sealed with strong tape
- The box is placed in an outer box with packing material to protect
it from vibration and movement
- The outer box is labeled with the address and weight of the package
- The package is shipped by a reliable, insured carrier
FAQ:
- Q: What is the brand name of the Low Frequency Solar Inverter?
- A: The brand name of the Low Frequency Solar Inverter is KOMCO.
- Q: What is the model number of the Low Frequency Solar Inverter?
- A: The model number of the Low Frequency Solar Inverter is KO-ESP.
- Q: Where is the Low Frequency Solar Inverter manufactured?
- A: The Low Frequency Solar Inverter is manufactured in China.
- Q: What are the features of the Low Frequency Solar Inverter?
- A: The Low Frequency Solar Inverter has wide input voltage range,
low idle current, built-in DC switch, pure sine wave output, and
high efficiency.
- Q: What accessories are included with the Low Frequency Solar
Inverter?
- A: The Low Frequency Solar Inverter comes with a user manual and a
set of mounting screws.
